| Model → Points ↓ |
AFL 10w Ultra Slim | AFL 20w Ultra Slim | AFL 50w Ultra Slim | AFL 80w Ultra Slim | AFL 100w Ultra Slim |
|---|---|---|---|---|---|
| Watt | 10 W | 20 W | 50 W | 80 W | 100 W |
| Input Voltage | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz |
| Lumen | 900 LM | 1800 LM | 4800 LM | 7200 LM | 9000 LM |
| CRI | ≥ 80 | ≥ 80 | ≥ 80 | ≥ 80 | ≥ 80 |
| Body Material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Operating Temperature in Celsius | < 65° C | < 65° C | < 65° C | < 65° C | < 65° C |
| Light Angle in Deg | 120 ° | 120 ° | 120 ° | 120 ° | 120 ° |
| Led Life (Hours) | 50000 HR | 50000 HR | 50000 HR | 50000 HR | 50000 HR |
| Driver Efficiency | ≥ 0.90 | ≥ 0.90 | ≥ 0.90 | ≥ 0.90 | ≥ 0.90 |
| Fitting Dimenssions in MM | 118 * 127 * 43 mm | 183 * 78 * 45 mm | 283 * 273 * 65 mm | 285 * 352 * 105 mm | 284 * 354 * 89 mm |
| Cutting Size in MM | - | - | - | - | - |
| Color Temperature | WH/WW/GR | WH/WW/GR | WH/WW/GR | WH/WW | WH/WW |
| Model → Points ↓ |
AFL - RGB 10w Ultra Slim | AFL - RGB 30w Ultra Slim | AFL - RGB 50w Ultra Slim |
|---|---|---|---|
| Watt | 10 W | 30 W | 50 W |
| Input Voltage | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz | AC 100-240 V / 50-60 Hz |
| Lumen | 900 LM | 2700 LM | 4800 LM |
| CRI | ≥ 80 | ≥ 80 | ≥ 80 |
| Body Material | Aluminium | Aluminium | Aluminium |
| Operating Temperature in Celsius | < 65° C | < 65° C | < 65° C |
| Light Angle in Deg | 120 ° | 120 ° | 120 ° |
| Led Life (Hours) | 50000 HR | 50000 HR | 50000 HR |
| Driver Efficiency | ≥ 0.90 | ≥ 0.90 | ≥ 0.90 |
| Fitting Dimenssions in MM | 118 * 127 * 43 mm | 228 * 220 * 52 mm | 283 * 273 * 65 mm |
| Cutting Size in MM | - | - | - |
| Color Temperature | RGB | RGB | RGB |
NOTE: WH = Cool white 6000K, WW = Warm white 3000 K, NW = Natural white 4000 K
All fixtures are including drivers (Constant current, non dimmable)
Due to constant upgrades company reserves the right to change the models / size / specification, etc without prior notice.
